SA Power outage Blackstart in relatively plain English

On Wednesday 28 September 2016 at 4:16pm South Australia had a state wide power outage, a black start event.

I, like most people were still at work and managed to continue working for a couple of hours thanks to laptop batteries and mobile phone internet. Although riding my bike home would have been crazy given the storm and lack of traffic lights. Thankfully I got a lift home. By 11:06pm the power came back on at my place. Having the entire state’s power go out is certainly not something that happens very often, as such it begs the question as to what happened.

The short version

3 main power lines got damaged by the storm, all within less than a minute. The loss of power from them meant an increase in load from Victoria, the load was more than that connection could handle, to protect itself from overloading it disconnected. With such a sudden drop in power the remaining power generators also tripped.

The 3 main connections which were severed by the storm were 275,000 volt transmission lines. The really big ones that usually buzz. It is believed that a Tornado or at least very high wind gust caused the damage.

One of the High Voltage Power Lines Destroyed by the Storm
One of the High Voltage Power Lines Destroyed by the Storm (Source: ABC)



The more detailed explanation

It was the storm which caused the outage as it caused 3 high voltage power lines from the North of the state to be damaged with 22 towers damaged or destroyed. The 4th high voltage line also tripped, but was not directly damaged.
They all disconnected within the space of about 40 seconds. South Australia was using about 1,826MW of power at the time and without the 315MW of (wind) power from the connectors the energy needed to come from somewhere. There was increased load on the Heywood Interconnector to Victoria to compensate. This went from delivering 525MW to well over the 600MW maximum rating it was designed to transmit. As a protection measure the connection was dropped, meaning that within less than a minute (and most of it happening within a couple of seconds) the state was now 850MW-900MW short of power.
The unexpected disconnections also caused the frequency of the electricity supply to change to fast. The power in Australia aims to run at 50hz (the US has 60 cycles a second) and the frequency is allowed to change by 1 Hz/second and the power generators don’t run if it’s below 47 Hz. The loss of the link to Victoria caused the frequency to drop by 6 and 7 Hz per second, far more than is tolerable, thus the rest of the power generation, the wind generators and Torrens Island power station were all dropped and the state went black.

To restore power the electricity companies had to initiate a black start procedure. From 5:23pm Electranet went and selectively turned on the Heywood interconnector, trying to get power to Torrens Island. This was important as it’s a gas fired power station able to generate up to 1,280MW of power and thus can help offset the lost power from the disconnected power lines. unfortunately the power station needs a lot of electricity to start and attempts to do that with the backup power didn’t work and storm damage caused the secondary backup to fail. The priority was getting the power from Victoria to Torrens Island. The power station was back up and running at 9pm. Pelican Point power station was also switched on (it hadn’t been running prior to the blackout) and was generating power by 10:05pm
By midnight on Wednesday (28th), 80–90% of electricity that could be reconnected was. Unfortunately due to the power line failures the North was effectively cut off from the rest of the state and it wasn’t until 9pm on Friday (30th September) 2016, that the last remaining transmission line to the southern Eyre Peninsula, was restored.

There’s an interesting part about how the 4th line that tripped but wasn’t destroyed. Because of the damage to the lines it is practice and ElectraNet’s operating procedure to conduct a patrol before reconnecting a line when such a ground fault occurs. Unfortunately the continued rain, poor weather and high winds (with gusts up to 120Km/h) meant the helicopters were grounded. This meant some poor sods had to drive along hundreds of km’s of power lines making sure they were fine. Thankfully the 4th line was confirmed intact and reconnected around noon on Thursday. I would like to thank the people who had to put in heroic efforts to get the power restored. Thank you.



Power Generation before Blackstart
Power Generation before Blackstart

Weather

There’s an average of 16 tornadoes we know about a year in Australia and where they occurred is a known higher risk area during a time of higher activity. I’ve been told that whilst the Bureau of Meteorology can identify structures in the radar images that indicate the potential for tornadoes to develop, they can’t directly identify Tornadoes and instead rely on reports, or video from the public, emergency services and the like. Such evidence points to there being 4 tornadoes during the storm around and F1 and F2 in scale, thus it’s certainly possible there was winds up to 140Km/h that likely caused the damage to the towers.

Below is a video of a tornado forming outside Blyth on the day.



For those wanting to see a variety of stats related to electricity production check out the AER website.



Update :

There was over 200,000+ households without power on the 1st of Dec 2016 after the Heywood Interconnector dropped out the AEMO media statement mentions it was “Due to the need to balance the frequency of the network”, which further strengthens the case for Solar Thermal in Pt Augusta as such a power station would provide not just better energy security but also the Frequency Anxillary Control Services needed in this case.
